General Ventilation Air Filter Tester

BACK
General Ventilation Air Filter Tester

info@standard-groups.com Quote

Share

Standards:

Applications:

This test system is suitable for the field of ventilation and air conditioning, as well as the clean air conditioning field of the electronic industry, the nuclear industry, the pharmaceutical industry, the food industry and others.

Product Information:

It is designed and manufactured by the principle of European standard EN779: 2002 to conduct tests with counting method or weighing method. At the same time, it’s more suitable for domestic filter manufacturers on the product testing needs with a simple operation, easy and wide application range. You can easily obtain the product test data through the operating system test software of company's own research and development.



1) Temperature range: 10℃～38℃.
2) Relative humidity: 20%～65%.
3)  Particle size count  range in the upstream and downstream: 0.3μm-10.0μm.

1) Test air volume: 800 m3/h～5500 m3/h.
2) Resistance: 0-1000pa.
3)  Efficiency particle size range: 0.3μm-10.0μm.

1) The test pipes are made of stainless steel and the reasonable design reduces dust adhesion.
2) Used a variety of dust ways to meet the various requirements.
① Artificial dust (simulate atmosphere)   ② Aerosol generator
3) The majority of the main components are by our company with the convenient maintenance and low cost.
4) Software is easy to operate with reliable data.
