Horizontal tensile strength tester main components and performance characteristi

The horizontal tensile strength tester is mainly used to test the strain and breakage of optical fiber composite overhead earth wire (OPGW) and other products under rated test force or constant load tension. The machine consists of a mainframe, servo measurement and control system, test software, strong electrical control system, computer system, test collet and so on. The horizontal tensile tester is widely used for testing the mechanical properties of rubber, plastic, leather, wire and cable, fabric, fibre, paper, film, cord, canvas, non-woven fabric, steel wire and other metal and non-metal materials such as tensile, compression, bending, shearing, tearing, peeling and adhesive force.

The main components and performance characteristics of the horizontal tension tester are as follows



1. exquisite and elegant appearance design; high-strength materials carefully produced, novel and beautiful shape, reasonable structure, rigidity, good stability, comfortable and convenient operation. Our company has been paying great attention to the appearance of the products over the years, and has developed many products comparable to foreign models. Some of the testers have been protected by national appearance patents. 2. Key components. The use of international brands, such as servo systems, ball screws, the United States of America or the force transmission wheel spoke load sensor.



2. Advanced planetary reduction system with circular tooth-shaped synchronous belt, with the advantages of high efficiency, long life, low noise and maintenance-free. Adopt pure digital phase locked loop pulse control mode, no drifting zero, no misalignment.



3. Adopt high precision, low resistance, double nut preload backlash-free ball screw, improve the transmission efficiency and ensure the displacement measurement accuracy of the crosshead. Choose series servo driver and servo motor, the main machine runs smoothly, high control precision, running noise is less than 51dB. Adopt circular toothed belt and toothed pulley, excellent meshing state, smooth loading without gap, long life of the testing machine, good long-term stability and energy saving. Long life Long life.



4. A variety of protection measures. Such as power link of various electrical protection, software part of the overload, over displacement protection, mechanical forced safety limit protection, etc.



5. simple, reliable and powerful user interface.



6. Open data structure, both result parameters and process data allow users to call randomly, which is very beneficial for research and teaching.



7. User-edited report function. The data can be conveniently imported into an Excel spreadsheet for easy post-processing by the user.



8. The crosshead travel display scale, which visually reflects the position of the crosshead, is used to set the safe movement interval of the crosshead, i.e. the software limit. The limit limit protection gear is used for limit protection of the travel of the crosshead (cutting off the power supply); the programmed limit protection gear is used for the safe operation of the crosshead when the power supply is not cut off. The remote manual control box is used to adjust the position of the moving beam, which can be moved at will, enhancing ease of operation.
