Medical gloves puncture resistance tester

The puncture resistance of medical gloves is directly related to the function of the gloves to block bacteria or viruses, so the control of this index is very important. The ability of a medical glove to resist puncture is directly characterized by the force required to puncture the specimen.



The main parameters:



7 inch touch screen

Chinese and English switching, easy to operate, beautiful atmosphere

1 set of special fixture

Embedded micro-printer, intuitive test data results

Speed: 0-200mm/min (factory setting parameters, speed can be adjusted arbitrarily)

Test software: American CSI

Force sensor: 0-10N

Drive structure: stepping motor plus high-precision ball screw, stable movement, high precision, accurate positioning

manual clamping;

Power supply: AC 220V 50Hz/120V 60Hz

Dimensions: 480mm(L)×480mm(W)×650mm(H)

Approximate net weight: 90kg




Executive standard:

"YY∕T 0616.4-2018 Disposable Medical Gloves Part 4: Puncture Resistance Test Method" standard stipulates that the professional puncture device required by the standard should be equipped with a professional puncture device and clamped on the testing machine. Moving at a constant speed, the sample puncture test was carried out, and a total of 12 puncture resistance measurements were performed, and the average value was calculated.





The medical glove puncture resistance tester developed and produced by Standard International is suitable for the puncture resistance test performance of medical gloves, also known as disposable medical glove puncture tester, medical glove puncture resistance tester and rubber glove puncture resistance performance test This testing instrument has a 0.1-level high-precision sensor, equipped with a professional puncture test device, easy to operate, and automatic test.
