Product Introduction:

The patented product is composed of protective clothing, temperature control system, ventilation pipe and pressure system. The clothing adopts multi-layer structure to ensure the heat insulation effect; the control system can be connected with the communication system of the robot.

The applicable ambient temperature range is - 40 — 70 ℃， with intelligent temperature regulation, remote monitoring, anti leakage protection and other functions.

It can be used in the cold storage of aquatic products, low temperature preservation, pharmaceutical factories, cold areas in the north, tropical areas and other extreme high and low temperature environments.

User pain point:

Existing Problems:Extreme low temperature,Extreme high temperature,Lubricant solidification,Motor overheating;

User loss:Robot stop,Equipment failure,Motor damage,Line down;

Advantages:

Heat-resisting

Cold-resistant

Insulation

Ventilation

Application industry：

Climate simulation,Cold storage,Low temperatur,Pharmaceutical,Metalworking,Smelting industry,Spare parts

Design advantage:

Digital remote design,No field measurement required,Short supply cycle,High precision design,Only 2D & 3D digital analog, on-site video and pipeline trend are required.

Product details:

Base pendulum:A large skirt is arranged at the place with a large movement amplitude of the first axis, so that the space increases after inflation and does not interfere with the operation of the robot.

Elastic structure at connecting rod:The lateral elastic ring binds the protective clothing to avoid excessive expansion due to internal air pressure.

Pipeline hanging buckle:A pipeline hanging buckle is added at the lower end of the arm to facilitate the fixation of the pipeline.

Six axis end closure:The protective clothing is fixed on the robot by the double closing way of elastic belt and tie belt to prevent the exchange of internal and external gas from affecting the temperature control effect.

Protective effect:

High quality + safety Escort + intimate service = spring rain protection

Spring Rain Protection Inspiration has become a leading domestic and internationally competitive protection product company.
